一个STM A179 U Bend Tubes

We bend ASTM A179 U Bend Tubes with round, rectangular, square, plus oval cross sections used in medical, automotive, plus electronics industries.

一个STM A179 U-Bending tubes are widely used in Heat-exchangers.
一个STM A179 U-Bending tubes are widely used in Heat-exchangers.

SA 213-T2 u-bended tube drawing
u-bend tube drawing

一个STM A179 U Bend Tubes for heat exchangers applied mostly in oil and gas plants, chemical and petrochemical plants, refineries, power plants and renewable energy plants. Low fin tubes can be supplied in the form of U bends.

U-bent tube sizes (u-bending, u-bend)

Tube Outside Diameter 管壁厚度 Bending Radius U Tube Straight “Leg” Length Straight Tube Before U Bending
min. 12,70 mm min. 0,70 mm min. 1,5 x D max. 11 000 mm max. 24 000 mm
max. 31,75 mm max 5,16 mm max. 1 250 mm

Sizes tolerances of U bend tubes are to fullfil the requirements of: ASTM A556 / 556M and DIN 28179

Heat treatment of U bent tubes

Post bending heat treatment by electrical resistance (Joule effect) is applied. The temperature is monitored and controlled during the process. It is possible to perform the heat treatment in a nitrogen atmosphere.

U bent tubes can be tested as follows

一个ll materials are hydro-tested as standard. Stress relieving is carried out in a gas-fired furnace or solution annealed using an induction heat process. We can offer a range of additional testing on request, including dye penetrant and PMI testing.

Bending Type:

Cold Bending and Hot Bending.

Heat Treatment:

一个fter Cold Bending, the bending area needs heat treatment.

一个STM A179 U-Bending tubes
一个STM A179 U-Bending tubes
一个STM A179 Utubes
一个STM A179 Utubes

Material Comparison Tables (ASTM ℃KS, JIS, DIN, BS, NBN, NF, UNI)

一个179 Seamless Cold Drawn Low-C Steel Heat Exchanger and Conderser Tubes
一个STM
UNS NO.
KOREA/JAPANES

GERMAN

BRITISH
BELGIAN
FRENCH
ITALIAN
KS/JIS Symbol
KS/JIS Numbe
Re
DIN Type

DIN

Materiral
Number

Re

B.S

B.S Grade
Re
NBN Type
NBN Grade
Re
一个F
NF
Re
UNI Type
UNI
Re
一个STM A179 K01200 STBH 340 / STB 35 D3563 / G3461 St 35.4 1629

1.0309

3606 CFS 320 D 37-2 629 (3b) TU 37 C 一个49-215 (3a) C 14 5462
St 35.8 17175 1.0305 Plus
DIN 2391 Gutegard C.NBK

Usage

U-bend tubes are widely used in heat-exchanger systems. Heat-exchanger equipment on the basis of seamless stainless U-tubes is essential in strategically important and critical fields — nuclear and petrochemical machine building.

"U bend tubes for heat exchangers applied mostly in Oil & Gas plants, Chemical & Petrochemical plants, Refineries, Power plants, Renewable energy plants."
  • Object medium: 10% sodium
  • hydroxide+5% sodium hypochlorite
  • Shell Diameter: ø 800
  • Working Pressure: 1.5mpa
  • Working Temperature: 40º C-90º C
  • Heat Exchange Surface Area: 100M2
  • Material: Gr1\Gr2

We are passionate about pipe bending:

Pipe bend, Bend pipe, Pipe bending, ANSI, ISO, JIS and DIN Standards, Measures 1/2 to 56 Inches.

The bend is used to change the direction of run of pipe.it advantage is can matach long distance transition requirements,so it is commonly that bends dimension according to customer design. usually,the bends consist of3D,5D,7Dand12Dseries.

Key Specifications/Special Features:

End bevel:according to the bevel of welding pipe fittings construction all the size can product according to the clients' requiry.

Pipe bend design

Standard:

Pressure:SCH5 to SCH160

Bending radius(R): R=3D,5D,7Dand12D
Bending angle (θ):15°, 30°, 45°, 60°, 90°, 135°,180°

Outer diamete(D): D≤1800mm
Wall thickness(T): T≤120mm
Straight Length (L): The length between two ends general from 300mm-1500mm

Materials

Industrial Processes

Bending, squeezing, pressing, forging, machining and more

Seamless pipeSpecification, standard and identification

Seamless pipes are extensively applied for the nuclear device, gas, petrochemical, ship building and boiler industries. Seamless pipes dominates 65% of market share in Chinese boiler industry.
